Ethernet Replacements For SONET

By: John Shepler

High bandwidth fiber optic Wide Area Networks have their basis in a decades old telephone company standard called SONET. Highly reliable, but highly expensive, SONET is giving way to the newer technology of Ethernet WAN. As demand for business bandwidth keeps increasing, so does the attractiveness of Ethernet for long distance connections.

Why SONET Ruled For So Long
SONET or Synchronous Optical Network was born out of a burgeoning demand for higher and higher levels of traffic. In this case, the traffic was long distance telephone calls. In the early days of telephony, this demand was met with dense webs of overhead copper lines.

Multi-channel analog technology made it possible for each copper pair to carry many phone conservations on a carrier-based system, much like many radio stations in a single band.

Digital technology eliminated the noise and crosstalk of carrier telephony by converting the analog conversations to pulse coded digital streams and multiplexing many together on a single pair. The transmission medium was still copper wire.

One thing about phone company standards is that they are all backwards compatible down to a single phone line. After all, that’s the telco business. So, the digital T1 lines were actually carrying 24 separate phone calls. A T3 line was 28 T1 lines or 672 phone calls.

When the fiber optic standard was developed, it picked up where copper left off. The OC3 SONET line is 155 Mbps and is equivalent to three T3 lines. Within all those multiplexed channels is the same 64 Kbps voice channel to support one phone call.

How did we get from really big phone lines to data transmission? Basically, SONET was the only game in town if you needed large amounts of bandwidth. So, all those voice channels in the line were combined to create one large data channel to carry packets of information. That requires protocol conversion circuitry to go from Ethernet network protocol to SONET telephone line protocol.

This works beautifully, but there are a few issues. For one thing, SONET levels are very specific and not scalable. If you want to move up from, say, a 155 Mbps OC3 to a 622 Mbps OC-12, you’ll at least need to swap out the termination controller or interface card in your router. Also, since analog phone traffic is now trivial compared to packet based data traffic, wouldn’t it be more efficient to just keep everything Ethernet from end to end? Indeed, it would.

Ethernet Replacements For SONET
Most competitive carriers and even many of the traditional telecom companies have adopted Ethernet as their network standard, as that’s where the traffic is. As a result, you can find much better pricing for Ethernet circuits than for traditional SONET. Ethernet WAN is also highly scalable. If you install a Gigabit Ethernet port, you can order service at any bandwidth level up to 1 Gbps. That covers OC-3 at 155 Mbps, OC-12 at 622 Mbps and pretty much OC-24 at 1.2 Gbps.

No hardware changes are needed until you require more 1 Gbps. At that point you may install a 10 Gbps port which will cover OC-24, plus OC-48 at 2.5 Gbps and OC-192 at 10 Gbps. Today, 100 Gbps is becoming more and more available to take the place of OC-768 at 40 Gbps.

If you are looking to upgrade your fiber optic WAN connections or are just curious about how much you might save by switching from SONET to Ethernet WAN service, you can easily get a set of competitive quotes from multiple service providers with no obligation. That applies to private line services, including cloud communications, as well as dedicated Internet access. Now would be a good time to make that inquiry.

Ethernet WAN is the New SONET

By: John Shepler

High speed communications lines progressed from copper analog to copper digital to fiber optic digital over most of the last century. The technology that drives fiber has also evolved from time sliced synchronous multiplexing to packet based protocols, mirroring the transition to networked computing for nearly every business. While older SONET telco lines still provide effective connections, there are real advantages to be gained by upgrading to Ethernet WAN, the newer technology for fiber optic service.

It Started With Really Fast Phone Lines
SONET, which stands for Synchronous Optical NETwork, is a phone company invention that was developed to bundle or multiplex thousands of individual phone calls onto an optical fiber for long distance transmission. To make operations easier, SONET was made backwards compatible with legacy T1 service that does exactly the same thing with 24 calls over two twisted copper pair… in other words, ordinary telephone line.

SONET allowed the phone companies to bundle T1 line into DS3 lines into OC3 fiber lines and demultiplex or unbundle them anywhere along the way. Everything was compatible down to the single telephone channel.

SONET to Link Computers
So, how did SONET come to support computer networking? The protocol had to be converted between SONET’s time division multiplexing and Ethernet’s packet switching. That was accomplished using protocol conversion on a plug-in module. To the user, It made no difference what was going on under the hood. Packets would go in one router and come out another miles or thousands of miles away.

SONET was developed for fiber and all of the early fiber optic links for computer networks were connected using one of the SONET levels. OC3 was the lowest speed at 155 Mbps. This was the first fiber service that most corporations ordered when they outgrew their T1 and T3 lines. Each increase in speed required swapping out an adaptor module for the particular SONET level.

In fact, the Internet was built on SONET. SONET rings, which offer redundant paths, formed the core of the Internet as it grew. Internet service providers would connect via SONET and then divvy up the bandwidth for multiple 64Kbps dial-up modems or, later, DSL or Cable broadband modems.

The Ethernet Revolution
Ethernet, developed by the Xerox Palo Alto Research Center in the mid to late 1970’s, grew to become the dominant networking protocol, thanks in no small part to the proliferation of the personal computer at the same time. Most small and large users adopted Ethernet, as adaptor cards, cabling, hubs and routers became more and more affordable. Every PC soon came with an RJ-45 Ethernet jack as standard equipment and peripherals, such as printers, did the same for compatibility.

Once Ethernet became the de-facto networking standard and computer data traffic greatly exceeded voice traffic, it started to make sense to just adopt Ethernet for Wide Area Networks as well as Local Area Networks. When business phones became digitized and used VoIP to connect on the same network as the computers, the need for a separate voice network faded away.

Another factor that has moved WAN services from SONET to Ethernet is the rise of competitive network service providers independent of the telephone companies. Since these companies had no legacy analog phone service to support, they could simply focus on offering Ethernet connections to their customers in competition to the telcos.

By this time the original Ethernet protocol has been expanded to provide technical specifications for Carrier Ethernet, which is the same as LAN Ethernet but extended to support the MAN (Metropolitan Area Network) and WAN (Wide Area Network).

What Ethernet WAN Has to Offer
You remember that SONET has distinct service levels, each with it’s own bandwidth and specific adaptor requirements. Ethernet doesn’t have this limitation. Instead, you have an Ethernet port with a maximum bandwidth, say 1 Gbps. It will support any bandwidth up to the max limit of 1 Gbps. You can order 100 Mbps service today and easily upgrade to 500 Mbps or 1 Gbps later. Only if you want a service level above 1 Gbps, will you need to have a higher capacity port installed. This process is so seamless that many providers will let you change service levels at will by logging into your online account.

Ethernet services tend to be less expensive than SONET. Usually, much less expensive. You pay for the service level you want, be it 10 Mbps, 100 Mbps, 1 Gbps, 10 Gbps, and so on. Remember you can change this easily after you have service installed and your bill will be adjusted to the new level you select.

Since there are many, many competing Ethernet MAN and WAN service providers, pricing per Mbps has dropped rapidly over the years and continues to do so. Some of the service providers are the traditional telephone companies, but with much improved pricing. Others are independent carriers serving regional, national, or international areas. They can also provide excellent customer service, high reliability, and very good deals on bandwidth.

There are usually two types of service you’ll be interested in. One is a dedicated connection to the Internet at a bandwidth you select. The other is a point to point dedicated private line that is just like having a very long Ethernet cable connecting two LANs separated by many miles. These are useful for interconnecting main offices and branch offices, warehouse, manufacturing centers and so on with maximum performance and privacy. Another popular application is a direct connection between your offices and your cloud service provider. This avoids the vagaries of Internet performance and makes the cloud seem like it is right down the hall.

Perhaps you still have legacy SONET service that was installed years ago. It’s been working fine so no one has paid much attention. This would be a good time to see if competing Ethernet WAN services can give you more bandwidth for the same budget or offer a considerable cost savings if you are happy with the bandwidth level you have now. It doesn’t cost anything to look, so why not see what’s available?

10 Gbps Dedicated Internet Access Has the Speed You Need

By John Shepler

Gigabit Internet is something of a gold standard for high speed business connections. Sometimes, though, even 1 Gbps doesn’t get the job done. At that point you need to consider a move up… to 10 Gigabit Internet.

Who Needs 10 Gbps Bandwidth?
Most small businesses and probably all residential Internet users have no real need for this performance. The bragging rights are far offset by significant monthly lease fees. This is serious bandwidth for demanding applications that make having it more than worth the cost.

Not long ago the only place you’d find 10 Gbps pipes were in the backbones of carrier networks, including the Internet itself. Time marches on and what was adequate a decade ago is marginal performance today. Those 10 Gbps lines have gone from rare and hard to get to fairly common and readily available to business.

Cloud services and colocation centers certainly need access to gigabit, 10 gigabit and even higher connection speeds. Large corporations with thousands of employees, all connected, can also justify this speed. High tech firms and those using high tech tools may also require higher speeds. Content providers? Absolutely. Hospital and medical centers with large imaging requirements certainly can’t be waiting around for file transfers.

What’s Involved In Acquiring 10 Gigabit Service?
Speeds this high are almost always going to be delivered on fiber optic cable. The interesting thing about fiber is that once you have it installed it is as easy to get high speeds as it is to get much more modest service. That’s because the fiber itself is capable of tremendous throughput. The limiting factors are the number of strands in the fiber bundle and the termination equipment on both ends.

The first standard for high speed fiber transmission was developed by the telephone companies and called SONET for Synchronous Optical NETwork. You may have heard of OC-192, which is the 10 Gbps SONET Optical Carrier level. Nowadays, most competitive networks and even the telcos are moving to Carrier Ethernet. Ethernet is directly compatible with nearly all local area networks. It is also easily scalable from typically 10 Mbps to 10 Gbps and even higher speeds. What’s even more important for most business users is that Carrier Ethernet, also called Ethernet over Fiber, is generally far more available and far less costly than the older SONET technology.

Many competitive regional, national and international carriers now offer 10 Gig Ethernet access as well as point to point private lines. That means you may have several competitive offers to consider.

Why 10 Gbps Dedicated Internet Access?
Think of the Internet as the proverbial electronic superhighway with a backbone of major interstate and international roadways and millions of on-ramps. Unless you are part of the Internet itself, you will be connecting through one of these on-ramps. They vary greatly in performance.

The best performance you can expect on the Internet is to connect to the network backbone through a high tier provider using a dedicated connection. Dedicated means that you and you alone have use of the bandwidth you have leased. That sounds like the way it should be, but most Internet connections designed for consumers and smaller businesses are shared, not dedicated. By multiplexing many customers on the same line, cable, satellite and cellular wireless companies can offer low cost reasonable speed connections to their customers.

The other characteristic to look for is symmetric bandwidth. That means 10 Gbps in both the upstream and downstream connections. Those low cost options are usually asymmetrical, with download speed high and upload speed low.

Bandwidth to Grow With Your Needs
Since Carrier Ethernet is so scalable, you can often order the bandwidth you need today with the option of upgrading incrementally as your needs grow. With a 10 Gbps port, you can order 1 Gbps, 5 Gbps or some other speed and pay for the performance you are actually using. As long as you have enough port speed, you can often upgrade with just a phone call to your supplier or even through your online account.

Are you cramped for bandwidth but concerned that what you really need is not available or too expensive? You’re likely in for a pleasant surprise, so go ahead and request competitive quotes from Dedicated Internet Access providers serving your business address.

Yes, You ARE Overpaying For Your Phone and Data Lines

By: John Shepler

With the economic future highly in question, every business needs to take a long, hard look at what it takes to survive. With future income uncertain and likely reduced, a good place to focus is on reducing expenses. Telecom lines, including data, telephone and Internet, can be a major monthly bill. It’s highly likely that right now you are paying more, perhaps much more, than you could be for the same quality of service.

Who’s Gouging Me?
Probably no one is cheating you or even taking advantage of your business. If you like, blame it on the gremlins. You know, those sneaky little critters that make everything break at the worst possible time. They also know how to bleed your budget without you ever knowing.

First, Get Rid of the Waste
You are paying for stuff you don’t need. I suspect you are paying for stuff that you don’t even use. How can that be? Anyone who has ever cleaned house has discovered all sorts of unopened christmas presents, products still in their original packaging, and food way past its safe date. The same is true in business. Things get bought. Some never get used. Others are used awhile, then the situation changes and they are set aside… just in case. Just in case never comes back again.

The worst offenders are subscriptions and contracts you pay for monthly but don’t get any value from. Right now, pull the bills for the last few months related to computing and telecom services. Services are especially sneaky at bleeding your budget because they are often out of sight and out of mind. You don’t trip over them like you do a big piece of equipment.

Now, grab a cup of coffee and go to a quiet space with your bills and some highlighters. You have to walk through these from top to bottom and question everything. Are there lines installed that aren’t being used anymore? Are there cell phone numbers that stopped being used when people left long ago? What about special fax machine lines, alarm connections, direct lines to buildings you got rid of? More DID numbers than you can possible use today? Toll Free numbers you don’t even advertise? Highlight them all. They’ve got to go.

Save a Bundle on What You DO Need
Now that you’ve made arrangements to delete all that extra costly clutter that adds no value, you’re left with the essentials. Of course you need phone lines and broadband service. You may need a direct connection to a cloud service provider or another office. You may well want managed security instead of having to keep someone on staff to fend off cybercriminals. Don’t cut so far to the bone that you hurt your ability to do business. Just get a better deal.

There’s a little secret about telecom services that escapes notice most of the time. Business lines, especially the dedicated ones like T1, DS3, SONET and Carrier Ethernet, are sold on contract. Usually you commit for at least a year, but probably take a 3 year contract for better pricing. Nothing wrong with that. It’s what happens at contract expiration that matters.

You might be tempted to simply renew the same contract at the same price, figuring you are lucky to avoid price inflation. Wrong. This industry is highly competitive and technology is advancing constantly. That translates into lower prices, not higher. For the same money you should get more bandwidth. Otherwise you should get a lower price for the next 3 years at the same bandwidth.

When New is Cheaper
Upgrading your technology could actually save rather than cost. Still nursing an old PBX system that needs maintenance and has pricy replacement parts? Have a look at
VoIP cloud service providers and let them manage the switching gear. All you need is phones and a SIP trunk to the cloud. You also gain new features that old analog desk phones can’t support.

Fiber optic bandwidth connections used to cost an arm and couple of legs. Not anymore. If you are in a built-up, not rural, area there is probably lots of fiber in the ground and overhead. Even the cable companies are leasing out extra fiber capacity. You might find that an upgrade in bandwidth could cost less than you pay for copper service now.

Running your own servers used to be the only way to go. Not anymore. In fact, it’s hard not to save money by pulling the plug and getting your infrastructure in the cloud. This is especially true if you need special high capacity lines to handle customer traffic. That bandwidth is likely cheaper at the remote data center and you’ll only need a lower bandwidth connection to manage the cloud services from your location.

Well, what do you think? Is there opportunity for cost saving in your business? Give these ideas at least a good look before you decide you are doing as well as you can. That includes getting a new current set of competitive quotes on all your line services, telephone, wireless and cloud services to see what might be available that you don’t know about.

Escape the High Cost of Bonded T1 Lines

By: John Shepler

The T1 line was the first professional-grade digital communications pipe. Over a half-century later, it is still widely used for point to point private lines and for PRI telephone trunking. It also makes an excellent first mile link for dedicated Internet access for small business. While the price of T1 lines have dropped dramatically over the years, it can still be a pricey solution, especially if you need to bond several together to get enough bandwidth. Are there any good alternatives?

The Good and the Bad of T1 Lines
At first, T1 lines were the only game in town. Once fiber became available with much higher bandwidth, T1 still had a cost advantage in the days before broadband everything. Would you believe that 1.5 Mbps was pretty impressive back in the day? It’s a symmetrical 1.5 Mbps. That’s the same speed in both directions. It’s also full duplex or both directions at the same time. T1 is a dedicated line. You have all the bandwidth and if you don’t use it, it just sits there idle until you do.

Bonded T1 Lines Increase Speed
Bonding is a process of making big lines out of little ones. If you bond two T1 lines, you get 3 Mbps. Four lines gets you 6 Mbps. Six lines and you have a respectable 9 Mbps. I understand that in the wilds of Alaska they’ll bond 8 or 10 lines together. That’s about the limit.

Now, the downside. Those 2, 4 or 6 bonded lines cost 2, 4 or 6 times as much as one T1 line. There’s no economy of scale. At, say, several hundred dollars a month each, that’s gets pretty pricey pretty fast. For that much money, why not just get a fiber optic connection?

Fiber Instead of Copper
Fiber, indeed. A nice side effect of the big telecom move to 4G LTE and 5G wireless is that the T1 lines they used to run to cell towers can’t possibly deliver the bandwidth. So, there has been a big buildout of fiber to the tower along with wireless fiber, also known as microwave transmission. That means that fiber service is far more available than it used to be. It’s also a lot less expensive due to increased competition from new providers and a technology switch from SONET to Carrier Ethernet. If you haven’t checked out fiber pricing and availability in awhile, you may be surprised at what has popped up while you weren’t looking.

Keep the Copper, But Use Ethernet
All that twisted pair copper in the ground can still be used to deliver decent bandwidths by bonding it for Ethernet over Copper instead of T1. EoC is a different technology and can deliver 10 or 20 Mbps easily. The downside is that bandwidth falls off rapidly with distance. This approach works best in populated areas where a telco office isn’t far away. If you can get it, Ethernet over Copper is very affordable and gives you the performance of bonded T1 at a fraction of the cost per Mbps.

How About Cable?
I’m amazed how many times prospective customers ask for gigabit fiber or dark fiber but wind up buying cable broadband. Why? Cable has a tremendous cost advantage. You can often get fiber bandwidths at T1 prices and most service levels are easily afforded by any business. The bandwidth is shared, not dedicated. It’s also asymmetrical, meaning that the download speed can be ten times the upload speed or more. These may or may not be issues, depending on how you use the service. Some applications just won’t tolerate anything but a private line. Most everything we do everyday isn’t that demanding. Many cable services have consistently high bandwidth and low latency. What hiccups there are tend to be transitory and long term outages have become rare on the major service providers.

Mix and Match
To get the right combination of performance and cost, you might want to consider a combination of services. For VoIP telephony and maybe business processes in the cloud, get a dedicated T1 or fiber connection. For general Internet use or customer WiFi, business cable broadband gives you a lot of performance for the price. Run the networks separately or use an SD-WAN system to intelligently direct traffic.

What bandwidth options are best for your business? Get pricing and availability on a wide variety of bandwidth services now so you can make the best decision and perhaps save considerable cost as well.

Fiber Optic Ethernet Transport Offers Huge Advantages

By: John Shepler

There are many ways to transport your data from one place to another. The new gold standard has become Fiber Optic Ethernet lines, also known as EoF or Ethernet over Fiber. You’ll have a hard time beating this solution on a cost/performance basis.

What is Fiber Optic Ethernet Transport?
Ethernet wasn’t part of the equation when fiber optic lines started to be buried in the ground and strung of utility poles for the telecom industry. The original standard was SONET (Synchronous Optical NETworking). This standard was designed to be backwards compatible with existing DS1 and DS3 multiplexed telephone calls in order to carry them on fiber. Why fiber? There's much more bandwidth in a single pair of optic fibers compared with legacy copper twisted pair, microwave and coaxial copper line.

Ethernet was born in the computer industry for local area networking. Transmitting this data outside the wired building or campus required a protocol conversion so that T-carrier and SONET fiber could carry packets instead of digitized phone calls. Decades later the efficiency of carrying Ethernet directly instead of first converting to an older protocol was standardized. Two varieties emerged. Ethernet over Copper and Ethernet over Fiber. For shorter distances, wireless Ethernet over line of sight microwave, laser, and radio systems such as WiFi and WiMAX were also developed.

The Immense Advantage of Fiber Optic Ethernet
Carrier Ethernet has been adopted by competitive telecom providers as well as the legacy telco companies. The first advantage is that it is directly compatible with computer networks. It’s Ethernet, after all. There is no need to deal with the inefficiency of converting back and forth between some other protocol. Just plug in your network and go. If you order a service such as E-LAN, you can interconnect your LANs at multiple locations as if they were on one big network.

The second big advantage is that Ethernet is easily scalable. When you order traditional MAN (Metropolitan Area Network) or WAN (Wide Area Network) services, you get a line with a fixed speed. T1 is 1.5 Mbps, DS3 is 45 Mbps and OC3 is 155 Mbps. That speed determines how much data you can transmit per unit of time and it also determines the price you pay. What’s more, if you outgrow your line service, you have to upgrade to another line standard and get all new termination equipment. A higher speed service may or may not even be available for upgrade.

With Fiber Ethernet you really don’t have an upper limit. Each fiber strand can carry maybe 10 Gbps and could be wavelength multiplexed with dozens or even hundreds of 10 Gbps channels. Fibers are so small that cable bundles might have over a hundred fiber strands. It’s going to be pretty hard to run out of capacity.

The nice part is that you don’t have to pay for all of that capacity. You order a service level, say 100 Mbps or 1 Gbps, and that’s what you are charged for. If you find that you need more, you can get upgraded to a higher service level with a phone call or even with an online portal. You can get as much bandwidth as the port capacity that is installed at your location. That’s typically 1 Gbps minimum, with options for 10 Gbps or even 100 Gbps.

Best Advantage of All
Thanks to competition in the marketplace and the enormous inherent capacity of optic fibers, the price you pay per Mbps is lower than it has ever been, and usually far better than with older SONET technology. That price is for highly reliable circuits, often with service level guarantees. The bandwidth is both symmetrical, same upload and download speed, and dedicated for your use only.

Competing Bandwidth Options
If you only need bandwidths of 10 or 25 Mbps, Ethernet over Copper can give you similar advantages to Ethernet over Fiber. At lower speeds, 1.5 or 3 Mbps, a T1 line is still attractive.

The bargain basement bandwidth options include business cable broadband, wireless Internet service providers, Satellite broadband, telephone DSL lines, and cellular broadband. All of these were developed for the price sensitive consumer market and then offered to small businesses with needs that aren’t too demanding. Prices per Mbps are very attractive. Most of this comes from the fact that bandwidth is shared among users and not dedicated to a single customer. Bandwidth is also non-symmetrical. Download speeds are typically 10x upload speeds.

Wireless services tend to have pretty restrictive usage limits and are not suitable for downloading big software updates or transferring large files. Satellite is available nearly everywhere, but has latency issues that make it difficult to use for telephone and other real-time services.

Note that these services are almost always Internet access only. Fiber Ethernet can be set up as dedicated Internet access or point to point private lines.

What bandwidth service is best for your business? You have many more options that you may realize and pricing that could be better than expected. Find out now, what Fiber Optic Ethernet services are available for your business locations.

Increase Your Bandwidth Beyond T1

By: John Shepler

You’e had your faithful T1 line service for years, maybe even decades. You love the reliability, solid bandwidth, low latency and the fact that prices have even declined from contract to contract. The one limitation that’s becoming a real bottleneck is the bandwidth. While 1.5 Mbps was plenty a decade ago, it’s not keeping up anymore. Is there any way to keep the performance of T1 but goose up the speed? Most definitely!

What Makes a Good T1 line Replacement
When you first took out your T1 contract, you chose this technology for good reasons. DSL was popular for business at the time, but notoriously unreliable. T1 had the advantage of being a service that was developed by the telephone companies for the telephone companies. That meant it was professional grade from the beginning and not a “consumer” service being offered for business as a cheap option.

T1’s fixed 1.5 Mbps bandwidth was dictated by the need to multiplex or combine 24 individual analog phone lines into a single digital equivalent that maintained all the voice quality, including minimal latency. T1 also had to run on existing twisted pair telco lines no matter how far they stretched. That’s why T1 is available far out into rural areas beyond the reach of other options.

T1 is still used to provide multiple phone lines for key telephone and PBX systems. It has been expanded to support packet-based digital networks including point to point dedicated lines and dedicated Internet access. Many T1 lines come with a Service Level Agreement (SLA) that provides a guarantee of availability and performance from the service provider.

Bonded T1
One way to increase the bandwidth of T1 lines is to simply add more of them. Most companies want that bandwidth combined, which is easily done by carriers using a process called bonding. All of the T1s you want bonded must be from the same provider. Two T1 lines gives you 3 Mbps, 4 lines give 6 Mbps and so on. You can go up to 10 or 12 bonded T1 lines, but the cost gets prohibitive unless this is your only option.

Ethernet over Copper
Ethernet over Copper uses the same twisted pair infrastructure as T1, but a newer modulation technology. You lose the unlimited distance advantage but gain much higher bandwidths, generally up to 10 or 20 Mbps, at more reasonable prices. If you are located in a populated area, EoC can give you the service you want at a fraction of the cost of bonded T1 lines.

DS3 Bandwidth
DS3 is part of the T-Carrier specification that also defines T1. DS3 offers 45 Mbps, enough for many businesses. Low latency, dedicated lines and reliable service are similar to T1 lines. The only wrinkle is that the higher bandwidth of DS3 isn’t supported over twisted pair copper. Instead, DS3 rides a fiber optic backbone to the curb and then a pair of small diameter coaxial copper lines to your router DS3 interface card.

Fiber Optic Service
Fiber service used to be well beyond the financial reach of most companies even if it was available… and it often wasn’t. That’s all changed. SONET technology, which transports DS3 and the higher bandwidth services like OC3, OC 12, and OC48, has become more available and less expensive. Ethernet over Fiber is the newer technology and it is much less expensive for the same high quality service. Many, many companies order 10 Mbps Ethernet over Fiber service and then easily upgrade to 50 or 100 Mbps as they need it. Bandwidths are readily available to 1 Gbps and even 10 Gbps in many areas.

What about Cable, Satellite, Wireless, Etc?
These less expensive services are shared, not dedicated bandwidth. That’s a major reason they are less expensive. Most are asymmetrical, meaning that upload speed is only a fraction of download speed. Satellite has tremendous latency effects and both satellite and wireless tend to have data caps. That said, a lot of businesses are saving a lot of money each month, especially if they combine a couple of low cost broadband services in a SD-WAN or Software Defined Wide Area Network. It all depends on how demanding your applications are and whether you prefer to avoid the Internet to connect locations. Get some expert advice and then pick the best bandwidth option appropriate for your business needs.

Is It Time To Go Fiber Optic Internet?

By: John Shepler

You’ve outgrown the Internet service that has served you well all these years. Business has changed and yours has expanded to the point that your Internet connection is getting in the way. Everyone would be more productive and less frustrated with a connection that didn’t impose limits. So, what should you do?

More Choices, Less Cost
You might be cringing at the thought of shopping for better Internet access. The last time you did that, pickings were slim. Few providers offering few services, most of which were very expensive. You may have wound up with a T1 line or DSL from your telephone company or a business cable offering from your Cable TV company. Has anything changed?

Oh, yes. Pretty much everything has changed. Actually, the choices have expanded and gotten cheaper across the board. You can still still order T1 lines. Today you’ll find there are more providers vying for your business and the prices may be a fraction of what you paid to sign your service contract years ago. Other than cost, though, T1 is still a 1.5 Mbps service. It may be adequate for the smallest businesses, but most everyone else will find the 1.5 Mbps limit stifling.

A more expansive option may be Ethernet over Copper. This is newer technology running on the same twisted pair telco lines. Bandwidth options vary from 1 Mbps up to typically 15 or 20 Mbps. Pricing is maybe half the cost of T1 per Mbps.

How about business cable? Yes, it’s still here but better. Modems have been upgraded a couple of times and now easily offer 100 Mbps, 300 Mbps and even 1,000 Mbps on the same coaxial cable. You may even get that 1,000 Mbps for the what you are paying for the old T1 line. Just be aware that the bandwidth on the cable line is shared and may vary during the day. Upload speeds are maybe a tenth of the download speeds.

How About Fiber?
Fiber optic Internet service was beyond the reach of all but the largest companies for decades. No more. A technology improvement from the old telco SONET to competitive Ethernet over Fiber has caused prices to plummet and options to multiply. You can pretty much dictate your bandwidth from 10 Mbps to 10 Gbps and order what you need without over paying. Later, when your needs expand, you can scale up your line speed, usually without changing hardware.

Ethernet over Fiber has the options of speeds as high as 100 Gbps that are easily scalable, highly reliable, dedicated and symmetrical. More and more, those options include ready availability from one and often several vendors. Most providers are aggressively building out their networks and may be able to minimize or even waive construction costs. It just depends on what’s available near your location and how much competition there is.

I Want Fiber. How Do I Get It?
You’ll probably never regret taking the plunge on fiber optic Internet service. Unlike older copper-based technologies, fiber is pretty much future proof as well as minimizing limitations such as latency, packet loss and jitter. It’s the transparent connection you are longing for.

Now, how to get service. Your best option is to work with a bandwidth broker like Telarus. They have contracts with dozens of providers serving the nation with connections that can go around the world. Your cost will be no higher than if you found a particular carrier yourself and probably less, since there are often multiple providers to choose from. Want to see what’s available right now? Get a quick budgetary quote online now and followup with possible special deals that aren’t advertised.

Lit Buildings Have Near Infinite Bandwidth

By: John Shepler

Among the many opportunities for locating your business, one group of buildings is special. These are the lit buildings, otherwise known as fiber lit buildings. Find one of these and your bandwidth woes will be over.

Lit Building Definition
What is a lit building? In this case, it’s not a building with all the lights turned on. The lit building meaning is that this particular facility is already “lit” for fiber optic Internet and, likely, point to point bandwidth service. The light this is referring to is the laser beam that shines down the glass fibers to transport digital signals at high speeds.

What’s So Great About Fiber Lit Buildings?
Pretty much every business today, from the smallest hamburger stand to the largest multinational corporation has a need to communicate electronically. Do you or any of your employees ever use a computer? Obviously, you have a need for connectivity. Even the smallest retail businesses have to process credit cards and likely need to place Internet orders, send and receive emails. and perhaps run a website. If you are not online, you are probably not in business.

Seems obvious, until you move into a new facility and find out there is no Internet in the place. If it’s a stand alone building or you are the first tenant in a strip center, office building or warehouse, you’ll be the one who has to order service and have it installed. It’s then that you find out that there are construction costs involved in bringing in the cabling and having the termination equipment set up and working with the provider. That’s all before you can plug-in your network.

Lit buildings take most of that grief away because the expensive and time consuming construction work has already been done. All you need to do is contract with the carrier who has lit the building to add an account for your business. Then just plug in your router to the termination point they give you and… Voila! … you are up and running.

What Services Are Available in Lit Buildings?
The advantage that fiber optic connections have over traditional landlines and even cable is that they can support nearly infinite bandwidth. Oh, there are technical limits to how many Gigabits or Terabits per second you can cram through a fiber strand, but they are pretty hard to breach. The modulation and multiplexing techniques are getting more sophisticated every day, leading to new upper limits on bandwidth through even a single fiber strand. A 10 Gbps service is no challenge. Now 100 Gbps is getting easy to come by. If that’s not enough to support an industrial park or office campus, fiber cables can bundle 100 or more individual strands that each operate independently.

The range of services available spans pretty much everything you can ask for. Most popular is Ethernet over Fiber, which is directly compatible in nearly all LANs. Bandwidth is easily scalable from 10 Mbps to 10 Gbps and beyond. Many carriers are now giving users portal access so they can adjust service bandwidth at will. Traditional SONET services like OC3 to OC48 may also be available. These can even be demultiplexed to provide traditional T1 line or ISDN PRI phone service. SIP trunking for VoIP and direct cloud connections are generally a standard offering.

Why NOT Go With Fiber?
Fiber is a truly transparent bandwidth transport in the literal sense of the word. It’s future proof and easily scales to meet your needs as your business grows. The only hangup may be that fiber is often not the least expensive solution for very small businesses and tight budgets. For that, the service of choice is business cable broadband. As long as the cable passes your location, you can probably get hooked up with 1000 Mbps of asymmetrical shared bandwidth at a bargain price. Many times there isn’t even a construction fee. Also, availability of cable is completely unrelated to whether the building is already lit for fiber.

Are you considering a move? Before signing a lease, make sure your bandwidth needs will be met now and for as long as you’ll stay there. Check for lit building fiber optic services and cable broadband availability now, to be sure.

Modernize Your T3 & DS3 Bandwidth Connections

By: John Shepler

Companies that grew up with T1 lines naturally graduated to T3 lines or DS3 connections as their bandwidth needs increased. These technologies are firmly established to deliver secure reliable bandwidth with low latency, packet loss and jitter. While you may be perfectly happy with the line service you have now, you might also be missing out on some advantages of new technology approaches.


T-Carrier Legacy
The story begins with the development of T1 lines starting after WWII. The impetus to create a new telephone trunking system was driven by the high cost and noisy performance of analog carrier telephony for long distance lines. T1 was the first digital replacement. It offered 24 digitized telephone lines on two pair of ordinary twisted pair telco cable. Each independent channel was time division multiplexed into a data stream running at 1.5 Mbps.

That’s still the spec for T1 lines. You can find the same channelized lines in use today for ISDN PRI telephone trunks to PBX phone systems. It’s organized as 23 phone lines and 1 control channel. Most T1 lines, though, have the channels combined to transport a 1.5 Mbps bit stream for data transmission. T1 lines can be combined or bonded to create larger “pipes”, up to about 10 or 12 Mbps.

T3 & DS3 Upgrade
T3 and DS3 use multiplexing compatible with T1 lines to create 28x the bandwidth or about 45 Mbps. T3 lines require frequencies too high to travel very far on twisted pair copper. T3 was originally provisioned on coaxial cable or via microwave towers. Later, fiber optic lines were implemented for long haul, with small diameter coax to the customer handoff in the building.

You might be wondering what the difference is between T3 and DS3. T3 is the physical circuit, coaxial cable or microwave link. DS3 is the signal that rides on the T3 line. The situation is similar for T1 lines. In that case, the signal is called DS1.

SONET Fiber Optic
Even the 45 Mbps bandwidth of a T3 line soon became a limiting factor for long distance telephony and the rise of digital computing. The next telco standard was a fiber optic definition called SONET for Synchronous Optical NETwork. SONET was designed to be compatible with DS1 and DS3 so that it was easy to multiplex or combine multiple DS3s onto, say, an OC3 at 156 Mbps. OC12 offers even higher bandwidth and OC48 was the prevailing network core bandwidth until recently.

Carrier Ethernet is a Game Changer
T-Carrier (T1 and T3) and SONET were products of the telephone companies and more suited to channelized telephony than computer data. Through a protocol conversion process they can be made to carry the standard Ethernet signals that run on LAN networks, but why not just keep everything in the Ethernet format end to end?

Why not, indeed! This is what Carrier Ethernet does. It replaces the earlier telco standards with long distance Ethernet directly compatible with in-house network connections. Instead of T1, T3, OC3, OC12 and OC48, you have Ethernet, Fast Ethernet, Gigabit Ethernet, 10 GigE and so on. A major difference is that Ethernet is easily scalable, while T-Carrier and SONET require equipment changes whenever you move to a higher standard.

Modernizing to Ethernet Connections
Carrier Ethernet networks, sometimes called IP networks because the protocol is the same as what is used on the Internet, are expanding rapidly to replace older Metro and Wide Area Networks. They offer the same dedicated, symmetrical bandwidth low in latency, packet loss and jitter. You can order point to point connections or dedicated connections to the Internet.

Ethernet comes in both copper and fiber options. Ethernet over Copper is a good upgrade for T1 from 3 Mbps up to 15Mbps, 20 Mbps or even more. Entry level Ethernet over Fiber is around 10 Mbps. Fiber is easily scaled to 50 Mbps that can replace T3 or DS3. It can also ramp up to 100 Mbps Fast Ethernet, 1000 Mbps Gigabit Ethernet and 10,000 10 Gigabit Ethernet. Even 100 Gbps Ethernet is available in some areas.

An Even Lower Cost Alternative
Business Cable Broadband is another service that has become extremely popular with small and medium size businesses. DOCSIS 3.0 and 3.1 modems offer an Ethernet connection to your network with speeds that easily reach 100 Mbps or 1 Gbps. An upgrade to 10 Gbps symmetrical bandwidth is being readied.

The attraction of cable is that it is readily available in most cities and often can be installed quickly with little or no construction charges. It is also the least cost per Mbps for the bandwidth you need. It is designed to work best for Internet browsing including video and file downloads. The bandwidth is generally asymmetrical, often as much as 10x as high in the download as upload direction. Cable bandwidth is shared, not dedicated, so you may find the speed varying throughout the day. Even so, many business and well and residential users are sold on cable broadband. For secure point to point connections you can use a VPN (Virtual Private Network) over the Internet.

Are you still on an old T3 or DS3 service contract? You’ll be amazed how much bandwidth you can get today for the same cost. Find out right now how many bandwidth providers serve your business location and what they offer.

Two Flavors of Fast Ethernet Service

By: John Shepler

No need to let bandwidth limitations stifle your business. Here are two affordable options to acquire 100 Mbps Fast Ethernet service, likely as much as a small to medium size operation will need. I’ll tell you later how to upgrade that to Gigabit Ethernet when the time is right.

Fast Ethernet over Fiber
The gold standard in business bandwidth has shifted from legacy T1 lines to fiber optic service. Not the old expensive SONET telco fiber that you know as OC-3, OC-12 or OC-48. I’m talking about the modern Carrier Ethernet standard known as Ethernet over Fiber, also called Metro Ethernet.

Entry level fiber service typically starts at 10 Mbps. That’s enough for many small businesses with limited Internet or file transfer needs. With even a few employees or heavy use of cloud applications, you’ll be craving more performance. That’s where Fast Ethernet shines. It offers 100 Mbps x 100 Mbps dedicated bandwidth 100% of the time.

Features of Fast Ethernet over Fiber
Performance is much like your old T1 line or DS3 connection, but much faster. Symmetrical bandwidth means that your upload and download speeds are both 100 Mbps. That’s important if you run cloud applications that send large files in both directions. Backup to cloud storage is almost exclusively in the upload direction until you need to recover a file.

Fiber optic bandwidth is known for low latency, packet loss and jitter. Your service will be solid since all of the line bandwidth is dedicated to your business. Whatever capacity you aren’t using at the moment sits idle, much like the way a Local Area Network behaves.

That brings up another important advantage of Fast Ethernet over Fiber. It is directly compatible with your LAN. Just plug it in to your router or switch and it’s ready to use. Many business networks run at 100 Mbps, although new installations are typically 1000 Mbps and larger networks are 10,000 Mbps or 10 GigE.

Option #2 Fast Ethernet over Cable
Business Cable Broadband has come a long way over the years. Most systems are HFC or Hybrid Fiber Cable. That architecture employs a private fiber optic network for the long haul runs. Traditional 75 ohm coaxial copper cable connects from the curb to your building. The termination equipment is a DOCSIS modem. Most are DOCSIS 3.0, which easily provides 100 Mbps Internet service up to a maximum of 1.2 Gbps in the download direction. The newer standard is DOCSIS 3.1, which easily provides Gigabit Internet service with a growth path to as high as 10 Gbps in both directions.

Characteristics of Fast Ethernet over Cable
Two advantages of Cable broadband are availability and cost. You can get service if the cable runs past your building, and that’s most buildings in metro areas. The cost for 100 Mbps Fast Ethernet is likely a fraction of what you pay for Ethernet over Fiber. Construction costs are minimal, if at all. Simply plug your network into the Ethernet connector on the DOCSIS modem.

The cost difference is reflected in a difference in service level, although that may not make a difference depending on how you use the service. Cable bandwidth is shared, not dedicated, which can mean variations in line speed that depend on how many other users are online and how heavily they are using the service.

The bandwidth is asymmetrical, meaning that download is much faster than upload. A typical bandwidth service is 100 Mbps down and 10 Mbps to 25 Mbps up. Typically Internet usage is heavily in the download direction for web browsing and watching video. Email is both upload and download, but the files tend to be fairly small and not affected by the asymmetry. If you send to large mailing lists to deliver video from your own servers, the upload bandwidth could become a limitation.

Upgrading Bandwidth
One advantage that both fiber and cable service share is that they are easily scalable compared to the old T-Carrier and SONET telco standards. You simply need a port that can handle the maximum bandwidth you anticipate needing. For fiber, that’s a Gigabit Ethernet port on the Customer Premises Equipment. For cable it’s a DOCSIS 3.0 or 3.1 modem. With those in place, you can upgrade your speed with just a phone call and no equipment changes will be necessary.

Do you feel limited by your current point to point or Internet access speed? You may be surprised how affordable a major upgrade is. Check out Fast Ethernet service options for your business now.

Swap Your Old T1 Line For Fiber

By: John Shepler

Your faithful T1 line has provided constant reliable service for years, perhaps decades. Now it’s getting a little long in the tooth. The 1.5 Mbps T1 offered amazing bandwidth at the dawn of the Internet era. Today it’s just plain sluggish. You know you need an upgrade, but how much is that going to cost? Would you be shocked to know that you might trade up for the same money? It’s true!

Why You Need to Make a Change
Let’s face it. You’ve run out of bandwidth. T1 still works well for small retail stores and other applications for POS credit card verification, email, small text files and very casual web browsing. Cloud services, video streaming, remote backups and large file transfers will crawl if they even work acceptably.

More of the Same Won’t Help
There’s nothing wrong with the line. It just doesn’t have enough bandwidth. You can bond a second T1 line or even a third to double or triple bandwidth, but you’ll also be doubling or tripling your costs. Unless you are in a remote location without other options, there is a better approach.

Fiber is the New Copper
Truth be told, the cost of T1 lines and most other telecom services have come down steadily over the years. If you are happy with your T1, you might be able to get the same service for half the cost you once paid.

Even better, the cost of fiber optic lines has plummeted over the same period. If you checked into fiber when you started your business and found it either wasn’t available or cost a small fortune, you are in for a pleasant surprise. Deregulation and the demand for higher and higher data speeds has resulted in a fiber building boom. The field is highly competitive and carriers are rushing to “light” buildings with their lines before someone else becomes established.

What this means for you is that fiber optic service is now commonly available. The latest offers are Carrier Ethernet which is also called Ethernet over Fiber. This technology is directly compatible with nearly all local area networks and replaces the older, more expensive SONET fiber service. SONET is the one you remember as costing a fortune.

Fiber for the Price of T1
Technology marches on. It’s been true for several years that you can upgrade your T1 line to a new technology called Ethernet over Copper and get at least twice the bandwidth for the same cost using the same twisted pair telco lines that supply your T1 service. Today, you can get several times the bandwidth using Ethernet over Copper. Same cost.

How about fiber? The latest competitive quotes I’m seeing offer entry level 10 Mbps x 10 Mbps fiber optic bandwidth for roughly the cost of a new T1 line in select areas. It is highly likely that you could get this level of fiber service for the same price as a T1 contract you’ve had for a few years or more.

Fiber For the Future
The nice thing about Ethernet over Fiber is that it is future proof. If your provider installs a 100 Mbps or 1 Gbps port, you can upgrade to those speeds any time, but only buy the speed you need right now. You may find the cost of Fast Ethernet at 100 Mbps or Gigabit Ethernet at 1000 Mbps really quite affordable and well worth it for the productivity improvement.

Are you frustrated by the inability of your T1 line or business DSL to keep up with your online needs? Now would be a great time to see what you can get in the way of a fiber optic bandwidth connection. You may be amazed by what is available today.

Encrypted Wavelengths Offer High Bandwidth and High Security

By: John Shepler

With data security becoming more and more of an issue, every weak link in the IT infrastructure needs to be identified and hardened. If your network extends beyond your premises, like most every one does, those MAN and WAN connections represent a vulnerability that has to be addressed. A relatively new service does that now for very high bandwidth users. It’s called Wavelength Encryption or Encrypted Waves.

Security of Dedicated Lines
The vulnerability of your connection can vary dramatically, depending on how your packets are getting from point A to point B. Back when the connectivity standard was a point to point T1 line, you had pretty decent security. A single line consisting of 2 twisted pair was dedicated to your use only. It was “nailed up”, as they say, meaning it was as close to a hard wire between two points that you could get. Only when you discontinued service was the connection “torn down” and the resources assigned to someone else.

Fiber Optic WAN and Multi-Tenant Networks
That’s not the way it is today. Unless you own a complete dark fiber run and light it yourself, you are sharing facilities with some and probably many other users. Note that you aren’t sharing bandwidth itself if you order a dedicated line. It’s just that high bandwidth fiber, be it SONET or Carrier Ethernet, is multiplexed to transport multiple streams of data and yours is simply stripped off the stream when it is delivered to your door.

It gets even more complicated in MPLS networks. These networks are multi-tenant by nature. The operator routes your data and that of other customers on the same core network and hands yours and only yours to you at the network edge.

Then, there's the Internet...
The security issues of the Internet need hardly be mentioned. You would have a hard time building a network that is less secure. But you don’t use the Internet for anything critical, right? If you have SDN connections over Cable Broadband or 4G Cellular, you probably are using the Internet for transport without realizing it.

Making the Insecure Secure
The answer to security jitters is encryption. On public networks, these encrypted data streams are said to be going through a “tunnel”. You can do the encryption and decryption yourself, or you can have your managed service provider take care of it.

Who Needs Encrypted Waves?
When it comes to high demand, high stakes uses, like medical data within hospital groups, there is a need for very high bandwidth channels that also have high security built-in. Level 3 Communications is at the frontier of a relatively new high performance connection called encrypted waves. These are based on the same wavelengths that are generated by coarse (CWDM) or dense (DWDM) wavelength division multiplexing. Each wavelength or set of wavelengths can deliver 10 to 100 Gbps of dedicated bandwidth. The multiplexing refers to multiple wavelengths, called colors or Lambdas, traveling over the same fiber strand. While leasing an entire wavelength does improve your security, encrypting that wavelength really adds security.

It’s simple in concept. The new wrinkle is that Level 3 is providing you with the wavelength already encrypted and protocol agnostic. Send whatever you want down the channel without having to worry about the nuts and bolts of securing that data stream.

Encrypted Wave Services Available Now
Here’s what Level 3’s Encrypted Wavelength service offers. The encryption is AES-256, the gold standard. You handle key management through your separate MyLevel3 portal that has two form factor authentication access. Ethernet speeds are supported at 10, 40 and 100 Gbps. SONET / SDH 10 Gbps is supported, as is OTU 2, 2e, 3 and 4. FICON and Fiber Channel (metro only) is supported at 8, 10 and 16 Gbps SAN. Low latency routes are optionally available for the highest performance.

Do you have high bandwidth needs that also require high security? You should take a closer look at what encrypted wavelength services have to offer. You may also be interested in dark fiber solutions. See what bandwidth options are available for your business locations now.

Metro Fiber Ethernet Gets You The Bandwidth You Need

By: John Shepler

Back when your company was smaller and business was slow, the old DSL or T1 line offered plenty of bandwidth to get the job done. Not so much anymore. Things have picked up and more of the content you need involves higher resolution graphics and video. Network congestion has your business throttled and that’s a bad situation.

Metro Fiber Ethernet Means Bandwidth
There is a clear trend in the telecom and network connection field. It is a gaining momentum toward everything fiber. That’s right, the fiber optic connections you used to take a pass on because of high cost or lack of availability are now ready for your business and at much better prices.

Fiber has the advantage over traditional twisted pair copper and wireless distribution because there is just about no limit to how fast those glass strands will run. Technology advances take the same glass fibers and increase the carrying capacity every few years. Too much data in the fiber bundle is a problem for the distant future, if ever.

What level of bandwidth is available now? Business users can generally get anything from 10 Mbps to 10 Gbps, with 100 Gbps in selected areas. Once your have the fiber installed, it’s your choice how much capacity to order. Same line, multiple bandwidth options.

Pay For Just What You Need
As fiber optic installations are multiplying, another technology is also taking over. That is, Carrier Ethernet. Yes, this is a compatible protocol with the Ethernet you already use on your Local Area Network. You simply plug into the Carrier’s termination, often a managed edge router, and you are connected to the Internet or via a private line across town or some other business location in the world.

Another beauty of Ethernet service is that there are no fixed bandwidth levels as there were with the older SONET fiber service. If you want 400 Mbps, you can get that. If you’d prefer 100 Mbps or 1,500 Mbps you can order those levels too. As long as the Ethernet Port installed at your location can handle the bandwidth, you can run at just about any speed.

This suggests a major cost savings for you. If your business level only requires 100 Mbps today, then order that. You may soon need 1000 Mbps, also called Gigabit Ethernet. No problem, call up your carrier and tell them to increase the speed of your line. They likely do that without any hardware changes and simply adjust your bill to reflect the increase in service level. You know that you have the flexibility to incrementally increase bandwidth as you really need the capacity.

More Availability, Less Money
You are no doubt aware that smartphones are getting faster and faster. 3G broadband is pretty much on the way out. Now it’s 4G everywhere, with 5G trials underway. One effect of this is that the old T1 lines that powered cell towers through 2G and 3G don’t have the capacity to support 4G and certainly not 5G. Support of high speed wireless has ironically caused fiber optic installations to boom. Fiber used to be rare and extremely pricey. Not so anymore. Pretty much all communication infrastructure being installed right now is fiber or wireless towers… or both.

All this fiber means capacity galore and lots of competition between a myriad of providers, all vying for businesses of all sizes. Even the Cable companies have gotten into the act recently. They’re offering access to their fiber optic networks that have the same quality of service as other business fiber services.

Why Metro Fiber Ethernet?
As the name suggests, metro fiber is more for locations within populated areas than out in the boonies. Metro also includes smaller cities, suburbs and business parks, not just major downtown areas.

What you want is competitive pricing on fiber based Ethernet bandwidth in a given metro area. Fortunately, that’s easy to find if you have the right tools. Want to see just how much bandwidth you can get for much lower prices than you’d expect? See how many Metro Fiber Ethernet Services are available for your business (not residential) location in a matter of a couple minutes.

Fiber Internet Availability and Lower Prices

By: John Shepler

It’s high time that most businesses make the move from wireline to fiber optic Internet service. Easy to say, but just how available is fiber these days and can I afford it? You’d be surprised how often the answer is YES.

What’s New With Fiber?
A decade ago, fiber optic bandwidth was only for large companies with big, big budgets. It was provided mostly by the incumbent telephone companies over SONET services such as OC-3, OC-12 and OC-48. IF you were located near enough to a fiber run to even qualify, the monthly bill was enough to make your eyes pop out.

Oh, that’s changed dramatically over the last few years. Now the most popular fiber services are Ethernet and the prices are not that dramatically higher than what you used to pay for a T1 or T3 line… and you get a lot more bandwidth. Entry level is now typically 10 Mbps and goes up to 10 Gbps, with 100 Gbps available in some areas. Need more than that? Really?

More Providers Mean More Availability, Better Deals
One major change is in who is providing fiber Internet service now. Yes, the big name telcos are still in the game with classic SONET service. But they’ve also built out the capability for Ethernet over Fiber and lowered prices dramatically. The better pricing comes from technology advances, but mostly from more competition.

Who’s the competition? It’s independent carriers that have built their own regional and national all-fiber networks. All that twisted pair copper in the ground belongs to the local telephone company. But fiber is a different game. Many providers have their own POPs (Points of Presence) that do not go through the telephone central offices. They don’t have to negotiate to lease the last mile connections. They simply install the runs themselves.

What’s So Great About Ethernet?
Are you kidding? Just what protocol is your LAN running? Today’s networks are all about data packets, not telephone calls. In fact, most of the traffic is actually digitized video. The standard interface is an Ethernet port, so why not keep everything in the Ethernet protocol from end to end?

Carrier Ethernet, as it is called, has other advantages. The newer Ethernet over Fiber networks are designed to be a lot more scalable. The old SONET system is set up with discrete levels of bandwidth and each one needs its own unique interface. Ethernet is Ethernet. Only the speed varies, so the interface remains the same. There will be a hardware change if you want to switch from RJ-45 copper to fiber optic for 10 Gbps and 100 Gbps. Otherwise, if your service provider installs a Gigabit Ethernet port you can change the bandwidth of your service from 10 Mbps to 1 Gbps at will. Not only can you upgrade quicker than ever, you only pay for the bandwidth you are using, not the full speed the line is capable of.

What About Installation?
This can be a bugaboo out in the boonies where there just isn’t much network infrastructure yet. In most cities, there is plenty of fiber in the ground and easy to access nearby. If your building is already “lit” with fiber installed and operating, you can get service quickly and easily without external construction costs. Otherwise, it depends. If the POP is close enough and you, or you and other some other tenants of the building, want enough service, the carrier might just eat the construction cost themselves. However, you may be asked to kick in some, so you’ll need to weigh that as part of the decision on how valuable fiber broadband is to your business.

I should note that some of the most aggressive fiber optic providers now are the cable companies. You think of them for television and coaxial cable broadband (DOCSIS). Cable broadband service is very inexpensive because it is shared among many users with the performance variations you’d expect. Behind the scenes, cable companies run their own fiber optic networks. Most of your town is probably lit for fiber other than the last segment of coax to your building. The cable companies can also make that a fiber run and connect you to their fiber optic network with dedicated symmetrical Internet access just like the telephone company and other providers.

Pricing and Availability
If you are a larger organization or your business is heavily dependent on applications in the cloud, you NEED fiber optic Internet service. You may be surprised by how much bandwidth you can get today at reasonable prices. Want to find out? Let’s check out fiber optic service availability and pricing for your business location.

Internet and Ethernet, The Perfect Broadband Match

By John Shepler

Broadband Internet connections come in many flavors. These include DSL, 3G & 4G cellular, PTP microwave wireless, cable DOCSIS, two-way satellite, T1 lines, DS3 bandwidth, SONET fiber optic, and both Ethernet over Copper and Ethernet over Fiber. Each of these has cost and performance advantages and disadvantages. One technology, however, offers the best match for most business applications. It’s the combination of Internet and Ethernet.

Why Ethernet?
What makes Ethernet so attractive is the fact that it has almost completely taken over wired networks large and small. Do you have a LAN? What protocol are you running? Unless it’s something specialized for storage or industrial control, the answer is almost certainly Ethernet.

Being dominant has it’s advantages. From a technical standpoint, dominance means that nearly every piece of network equipment comes with Ethernet connectors built-in. In most cases, these are 10/100/1000 Mbps RJ-45 jacks. At higher speeds, 10 GigE and higher for sure, fiber optic connectors will be included.

It’s also not just that Ethernet standards permeate every network such that you have a hard time building one to some other protocol. How much do those alternative networks cost? The dominance of Ethernet has led to economics of scale. Ethernet is now the low cost solution by far. It’s also the solution that is sourced everywhere. You have no trouble picking up cable, connectors, switches, routers, and everything that plays on a network.

The One Laggard… The WAN
Local Area Networks are firmly ensconced with Ethernet technology. Outside the plant, however, it’s not so clear-cut. Wide Area Networks evolved from different standards pioneered by the telephone companies and were not originally intended for computers. Telephone networks were invented first and they were all analog, both wired and wireless. Then, starting mid-20th century, the T1 digital standard was introduced for multiplexing phone lines and long distance transmission. T1 expanded into T3/DS3 for higher speed, followed by fiber optic standards based on the same TDM (Time Division Multiplexing) protocol.

Since the phone companies pretty much owned all telecommunications networks, Ethernet packets had to learn to ride on what was available. That meant protocol conversion from Ethernet to T1, and so on. This is still the case for traditional telecom networks, although that’s changing fast.

Carrier Ethernet Moves to the Front
The old collision domains are long gone for the most part. Networks now are switched Ethernet. It turns out that the switched Ethernet protocol are quite compatible with long distance networks with a few additions to the standard for operations and maintenance. Those standards have been created and go by the name of Carrier Ethernet.

As you might suspect, Carrier Ethernet is merely an extension of LAN Ethernet. There really is no protocol-conversion speed bump traversing from one to the other. You plug your network into the carrier’s premises equipment and your packets travel seamlessly for hundreds or thousands of miles.

Ethernet and the Internet
The Internet was designed as a computer to computer network from the get-go. When we talk about IP networks, the IP means Internet Protocol. When we talk about Ethernet protocol, we are generally referring to IP and perhaps the file transfer standard, TCP/IP.

When the Internet started, there were only the telephone company networks available, so the Internet began running on legacy telco standards, particularly SONET fiber optic. That’s changing now. More and more networks are Ethernet at their core. Most newer networking providers design their networks as IP from the start and don’t go depend on handoffs to the telephone company central offices.

Either way, as long as you have Ethernet to your premises, you can ignore what’s going on at the core of the network.

Ethernet’s Big Advantages
Carrier Ethernet services come in a wide variety of speeds, but they all stick to the same Ethernet standard. You simply specify the maximum speed of the port that is installed at your location. That’s generally 1 Gbps these days, although you can also opt for 10 Gbps and, in some cases, 100 Gbps. The port sets the maximum, not the minimum, broadband speed you can order. In fact, many companies start at 10 or 100 Mbps and then upgrade to Gigabit Ethernet or beyond when they need to. That means they only pay for the bandwidth they need.

Ethernet services also tend to be less expensive than traditional telco services for the same bandwidth. It’s fairly common to get 3 Mbps for the same or less cost than a single 1.5 Mbps T1 line. You might even get 10 Mbps for the budget you originally set for T1 Internet service.

That last mile connection to the Internet via dedicate Ethernet Internet access means that your bandwidth is symmetrical, or the same in the upload and download directions. It is also dedicated to your use 100% of the time. With other services, such as cable or cellular broadband, the bandwidth is shared among customers. That makes it cheaper, but also means that your share will vary depending on how many others are using the service at the same time.

Ordering Ethernet Internet Service
The best place to get your business broadband service is from a bandwidth broker, like Telarus, who has relationships with many carriers. You’ll likely have multiple options to choose from. The two flavors you’ll most likely encounter are Ethernet over Copper for lower speed options and Ethernet over Fiber for 50 Mbps and up. Fiber is highly desirable if your building is already lit or construction costs are low. Otherwise, you can almost always get some type of copper based delivery.

Interested in finding out what options you have and what they cost? Run a quick search for fiber optic Ethernet service here and see what pops up.

Data Caps: What They Are and How to Avoid Them

By: John Shepler

If you are a moderate or heavy online user, you have probably bumped up against data caps at some point. Just what's the story behind these seemingly arbitrary usage limits and how do you work around them?

OK, What IS a Data Cap?
A data cap is nothing more than a limit to the amount of data you can transfer through a communications channel over some period of time. While providers could set limits per hour or day, data caps are almost always defined now as so many MB or GB of usage per month. Your allocation is reset at the beginning of each month or 30 day period. You draw down your allocation over the time period as you surf the web, transfer photos, videos or data files, or backup your computer to the cloud. If you run out of data before you run out of month, there are consequences.

Why Caps Are Imposed
Data caps, especially tight ones, tend to be imposed on channels where capacity is limited. There are so many users and they each would like to have the link to themselves. If there isn't enough bandwidth to go around, the capacity that is available has to be rationed among the pool of users. This can be done by apportioning the bandwidth in Mbps among the pool of users. The other option is to let each user have the max bandwidth they are paying for but limit how much they can use the channel. That keeps heavy users from "hogging" the resources 24/7 so that lighter users never get much in the way of access.

Where do you find these data caps? Wireless services have had them from the get-go. Satellite is really another form of wireless and has similar usage limits. Wireline and fiber optic services have much more capacity than wireless channels, so the data caps are set much higher. While you might be limited to 20 GB per month on a LTE cellular wireless plan, that limit is more like 500 GB on a cable broadband plan. Only the heaviest Internet users will likely hit the cable usage limit so most people think there really is no limit.

It's important to note that data caps are really there to police fair usage of a limited resource that is shared among many users. All consumer broadband services and their equivalents sold to businesses are shared bandwidth services. The service provider buys an unlimited usage telecommunications line and then divvies it up to serve its paying customers. Each customer is assigned a bandwidth limit of "up to" so many Mbps and a usage limit of so many MB or GB per month. This arrangement keeps the most customers happy most of the time.

What Happens If You Go Over the Limit?
There are various ways of enforcing fair use of an Internet channel. Cellular plans started out setting a fixed usage limit and then automatically charging for every MB or GB you went over the limit. The danger of a plan like this is that you may not know how much you've exceeded your allocation until you get an astronomical bill. Most providers will give you the courtesy of a notification when you approach or exceed your limit to avoid the sticker shock.

A more draconian method of dealing with overages is to simply cut off service once the limit is reached. At that point you have to manually contact the provider and buy some extra capacity to get through the month or cease usage.

Neither of these usage limit methods goes over well with broadband customers. A kinder, gentler arrangement is to forget about cutting off service, but limit your access speed once you hit the limit. You might get throttled back to 10 percent or so of normal service bandwidth until your account resets at the start of the next billing period. This is unpleasant, but at least you can always get online to some extent.

What About Unlimited Usage Plans?
Check the fine print on your contract. You're likely to find something that specifies a "fair usage" limitation. Sometime they don't specify a hard limit but say that the provider has the right to impose fair usage restrictions. In fact, you may have all the capacity you want... at least for awhile. The fair usage clause tends to be imposed if you are someone who is using the service far and beyond what the bulk of other users are doing, or if the provider lands a lot of customers and doesn't have the ability anymore to give them all they want.

Services like satellite and cellular wireless have definite limitations due to the number of radio channels they are licensed to use and the carrying capacity of the particular technology they are using. Higher speed doesn't automatically get you higher data caps. If you aren't careful, that higher bandwidth will simply allow you to use up your allocation quicker.

Is There Any Way Around Data Caps?
You might not know this, but there are dedicated private lines and Internet connections that don't have any data limitations at all. These are the professional grade copper and fiber lines that the service providers themselves order and partition to sell to you and a hundred or a thousand other customers. Businesses, but not residential customers usually, can also order these telecom services and have all the capacity to themselves.

Typical line services are T1 at 1.5 Mbps, the classic standard, T3 or DS3 at 45 Mbps, OC3 SONET at 155 Mbps, Ethernet over Copper at 10 to 50 Mbps, and Ethernet over Fiber at 10 Mbps to 10 Gbps. These are called "dedicated" line services because all of the resources are dedicated to YOUR business. That means you get 100% of the line speed all the time. It also means that you get all of the line capacity. You can load up a 100 Mbps Ethernet line to full capacity for the entire month and not pay a penny extra. Your monthly lease cost is fixed.

How About Costs?
Well, that's the rub. You will pay more for a dedicated line service than you will for a shared bandwidth service, as you'd expect. Even so, there's little value is paying a low ball price for a service that doesn't give you the capacity you need. If you wind up paying overages every month, it might make a lot more sense to simply pay up for a line that doesn't have overages. You can then forget about having to watch your usage all the time or limit the activities of your employees.

When Does Dedicated Line Service Make Sense?
If your application naturally taxes the capacity of a communications line, such as a service or content provider or a company that has critical business applications in the cloud, you may be happier with dedicated line services beyond the unlimited usage. Dedicated lines have constant rather than varying bandwidth, plus low latency, jitter and packet loss.

What type of bandwidth service is best for your company and your applications? Check dedicated and shared bandwidth service options and get free consulting help now to help you sort through the options available for your business location.
